Ricoh Aficio SP 8100DN [192/340] Sending on demand e mail
![Ricoh Aficio SP 8100DN [192/340] Sending on demand e mail](/views2/1064372/page192/bgc0.png)
Monitoring and Configuring the Printer
180
5
Sending On-demand E-mail
To use on-demand e-mail notification, perform the following configuration
tasks in Web Image Monitor.
A In the menu area, click [E-mail].
B Make the following settings:
• E-mail Notification E-mail Address: Enter the address using alphanumeric
characters.
• Receive E-mail Notification: Specify whether to use on-demand e-mail no-
tification.
• E-mail Notification User Name: Enter the administrator's user name as the
mail originator name.
• E-mail Notification Password: Enter the password of the mail notification
user.
C Click [OK].
D Click [Logout].
E Quit Web Image Monitor.
❖ Format of on-demand e-mail messages
To use mail notification, you need to send an on-demand e-mail message to
this printer.
Using your mail software, enter the following:
Note
❒ A mail message must be within 1 MB in size.
❒ E-mail may be incomplete if sent immediately after power on.
Item Description
Subject (Referred to as Subject) Enter a request regarding the device. For de-
tails, see the table below.
From (Referred to as From) Specify a valid mail address. The device in-
formation will be sent to the address speci-
fied here.
