System Menu
135
4
System Menu
The System Menu allows you to set the printer's basic functions. Although you
can operate the printer using the default settings, you can also change its settings
to better suit your printing needs. Changes made to settings remain effective af-
ter power off.
Changing the system menu
Follow the procedure below to change the settings for Energy Saver Timer.
A Press the {Menu} key.
The [Menu] screen appears.
B Press {U} or {T} key to display [System], and then press the {q Enter} key.
C Press {U} or {T} key to display [Energy Saver], and then press the {q Enter}
key.
D Press the {U} or {T} key to select [E. Saver Timer], and then enter {q Enter}
key.
E Press {U} or {T} key to select the lead time needed to switch to the Energy
Saver mode.
F Press the {q Enter} key.
Wait two seconds. The [Energy Saver] screen appears.
G Press the {On Line} key.
The initial screen appears.
System menu parameters
This section explains about parameters that can be set on the System menu.
❖ Prt. Err Report
You can select [On] or [Off] to have an error report printed when a printer error
or memory error occurs.
•Off
•On
Note
❒ Default: Off
