Monitoring and Configuring the Printer
218
5
Cover Open: Lower Right Cover The lower right cover is open.
Cover Open: Right Cover The right cover is open.
Cover Open:Finisher Upper Left The upper left cover of Finisher is open.
Cover Open:Finisher Upper Right The upper right cover of Finisher is open.
Data Size Error The data size error occurred.
Empty: Black Toner The black toner cartridge is almost empty.
Energy Saver Mode The printer is in Energy Saver Mode.
Error An error has occurred.
Error at Printer: Red LED An error has occurred.
Error in Printer An error has occurred.
Error: Address Book An error has occurred in the data of the ad-
dress book.
Error: Command Transmission An error has occurred in the printer.
Error: DIMM Value A memory error occurred.
Error: Ethernet Board An Ethernet board error has occurred.
Error: HDD Board A hard disk drive board error has occurred.
Error: Media Link Board A hard media link board error has occurred.
Error: Memory Switch A memory switch error has occurred.
Error: Optional Font An error has occurred in the font file of the
printer.
Error: Optional RAM An error has occurred in the optional memory
unit.
Error: Parallel I/F Board An error has occurred in the parallel interface.
Error: PDL An error has occurred in the page description
language.
Error: Rem. Certificate Renewal An error has occurred in the remote certificate
renewal.
Error: USB Board An error has occurred in the USB board.
Error: USB Interface An error has occurred in the USB interface.
Error: Wireless Board An error has occurred in the wireless board.
Error: Wireless Card Wireless card is not inserted during start up,
or the IEEE 802.11b interface unit or the wire-
less card is taken out after start up.
Exceed Booklet Stapling Limit The printing has exceeded the stapling limit of
the booklet finisher.
Full: Finisher Finisher tray is full.
Full: Finisher Booklet Tray Finisher booklet tray is full.
Full: Finisher Shift Tray Shift tray of Finisher is full.
