Ricoh Aficio SP 8100DN [216/340] Access type configuration
![Ricoh Aficio SP 8100DN [216/340] Access type configuration](/views2/1064372/page216/bgd8.png)
Monitoring and Configuring the Printer
204
5
❖ Community name configuration
msh> snmp “number” name “community_name”
• You can configure ten SNMP access settings numbered 1-10.
• The printer cannot be accessed from SmartDeviceMonitor for Admin or
SmartDeviceMonitor for Client if “public” is not registered in numbers 1-
10. When changing the community name, use SmartDeviceMonitor for
Admin and SNMP Setup Tool to correspond with printer settings.
• The community name can be entered using up to 15 characters.
❖ Deleting community name
msh> snmp “number” clear name
❖ Access type configuration
msh> snmp “number” type “access_type”
❖ Protocol configuration
msh> snmp {ipv4|ipv6|ipx} {on|off}
• Use the following command to set protocols “active” or “inactive”: If you
set a protocol “inactive”, all access settings for that protocol are disabled.
• Specify “ipv4” for IPv4, “ipv6” for IPv6, or “ipx” for IPX/SPX.
• {on} means “active” and {off} means “inactive”.
• All protocols cannot be turned off concurrently.
❖ Configuration of protocol for each registration number
msh> snmp “number” active {ipv4|ipv6|ipx} {on|off}
• To change the protocol of access settings, use the following command.
However, if you have disabled a protocol with the above command, acti-
vating it here has no effect.
Access type Type of access permission
no not accessible
read read only
write read and write
trap user is notified of trapmessages
