Ricoh Aficio SP 8100DN [255/340] Setting up as a print server netware 4 x 5 5 6 6
![Ricoh Aficio SP 8100DN [255/340] Setting up as a print server netware 4 x 5 5 6 6](/views2/1064372/page255/bgff.png)
Using NetWare
243
6
E Confirm the settings, and then click [OK].
Configuration is now complete. Wait several before restarting Web Image
Monitor.
F Click [Logout].
Note
❒ To check that the configuration is made correctly, enter the following from
the command prompt.
F:> USERLIST
❒ If the printer works as configured, the name of the print server appears as
a connected user.
❒ If you cannot identify the printer you want to configure, check the printer
name with the configuration page printed from the printer. For details
about printing a configuration page, see p.130 “List/Test Print Menu”.
❒ If no printer names appear in the list, match the frame types of IPX/SPXs
for the computer and printer. Use the [Network] dialog box of Windows to
change the frame type of the computer.
Setting Up as a Print Server (NetWare 4.x, 5/5.1, 6/6.5)
Follow the procedure below to connect the printer as a print server using Net-
Ware 4.x, NetWare 5/5.1, or NetWare 6.0.
Important
❒ When using the printer as a print server in NetWare 4.x, NetWare 5/5.1, or
NetWare 6.0, set it to the NDS mode.
❒ When using NetWare 5/5.1 or NetWare 6.0, set the printer as a print server.
A Start Web Image Monitor.
B Click [Login].
A dialog box for entering the login user name and password appears.
C Enter the login user name and password, and then click [Login].
For details about the login user name and password, consult your adminis-
trator.
D Click [Configuration] in the left area, and then click [NetWare Print Settings].
• Print Server Name: Enter the NetWare print server name. To use the inter-
face board as a print server, enter the name of a print server that is not ac-
tive on the file server. Use up to 47 characters.
• Logon Mode: Specify whether to designate a file server or NDS tree when
logging on to NetWare.
• File Server Name: When a file server name is entered here, only the speci-
fied file server is searched for. This item is mandatory. Use up to 47 char-
acters.
