Monitoring and Configuring the Printer
166
5
C Select a printer.
D On the [Tools] menu, point to [Device Settings], and then click [Lock Operation
Panel Menu].
A Web browser opens and the dialog box for entering the password for the
Web Image Monitor administrator appears.
E Enter the user name and password, and then click [Login].
For details about the user name and password, consult your administrator.
The [System] page of Web Image Monitor appears.
F Enter required setting items, and then click [OK].
G Click [Logout].
H Quit Web Image Monitor.
I Quit SmartDeviceMonitor for Admin.
Reference
For details about setting items, see Help in the [Device Settings] on [Configu-
ration] page.
Changing the Paper Type
Follow the procedure below to change the paper type.
A Start SmartDeviceMonitor for Admin.
B On the [Group:] menu, point to [Search Device], and then click [TCP/IP],
[IPX/SPX] or [TCP/IP SNMPv3].
A list of printers using the selected protocol appears.
Select the protocol of the printer whose configuration you want to change.
If you are using TCP/IP SNMPv3, enter the user authentication.
C In the list, select a printer whose configuration you want to change.
D On the [Tools] menu, point to [Device Settings], and then click [Select Paper
Type].
A Web browser opens and the dialog box for entering the password for the
Web Image Monitor administrator appears.
E Enter the user name and password, and then click [Login].
For details about the login user name and password, consult your adminis-
trator.
The [Paper] page appears.
F Select a paper type in the [Paper Type] list for each tray.
