Monitoring and Configuring the Printer
232
5
Attach FileServer= <file servername> Connection to the file server as the nearest
server has been established.
Attach to print queue <print queue name> (In the print server mode) Attached to the
print queue.
Authentication mode mismatch< SSID > Authentication mode is different to the AP. The
required SSID is the SSID of the access point
connected to when in infrastructure mode.
centrod is disabled. Communication via parallel connections una-
vailable because centrod is disabled in the se-
curity mode.
Enable centrod in the security mode.
Cannot create service connection (In the remote printer mode) Connection to the
file server has not been established. The
number of file server users may have exceeded
the maximum capacity of the file server.
Cannot find rprinter (<print server
name>/<printer number>)
The printer with the number displayed on the
print server does not exist. Make sure that the
printer number is registered on the print server.
Change IP address from DHCP Server. The IP address changes when DHCP lease is re-
newed. To always assign the same IP address,
set a static IP address to the DHCP server.
child process exec error! (process name) The network service failed to start. Turn the
printer off and then on. If this does not work,
contact your service or sales representative.
Client password rejected The client's password was rejected. Check the
client password.
Client tls certificate rejected The client's TLS certificate was rejected. Check
the certificate.
Connected DHCP Server(<DHCP serverad-
dress>).
The IP address was successfully received from
the DHCP server.
Could not attach to FileServer<error number> (In the remote printer mode) Connection to the
file server has not been established. The file
server has refused the connection. Check the
file server configuration.
Could not attach to PServer<print server> (In the remote printermode) Connection to the
print server has not been established. The
print server has refused the connection. Check
the print server configuration.
Current Interface Speed: xxxMbps Speed of the network (10Mbps, 100 Mbps, or
1Gbps).
Current IP address <currentIP address> Current IPv4 address.
Current IPX address<IPX address> Current IPX address
DHCP lease time expired. DHCP lease time has expired. The printer tries
to discover the DHCP server again. The IP ad-
dress until now becomes invalid.
Message Problem and solutions
