Making Printer Settings Using the Control Panel
128
4
❖ Tray 1
Plain Paper, Recycled Paper, Special Paper, Color Paper, Letterhead, Pre-
punched, Bond Paper, Preprinted
Note
❒ Default : Plain Paper
❒ For details about the type of paper loaded in each tray, see Hardware
Guide.
❒ Be sure to set a paper type using the control panel. If you do not set it,
the printing result might not be proper.
❖ Tray 2
Plain Paper, Recycled Paper, Special Paper, Color Paper, Letterhead, Pre-
punched, Bond Paper, Preprinted
Note
❒ Default : Plain Paper
❒ For details about the type of paper loaded in each tray, see Hardware
Guide.
❒ Be sure to set a paper type using the control panel. If you do not set it,
the printing result might not be proper.
❖ Tray 3
Plain Paper, Recycled Paper, Special Paper, Color Paper, Letterhead, Pre-
punched, Bond Paper, Preprinted
Note
❒ Default : Plain Paper
❒ For details about the type of paper loaded in each tray, see Hardware
Guide.
❒ Be sure to set a paper type using the control panel. If you do not set it,
the printing result might not be proper.
❖ Tray 4
Plain Paper, Recycled Paper, Special Paper, Color Paper, Letterhead, Pre-
punched, Bond Paper, Preprinted
Note
❒ Default : Plain Paper
❒ For details about the type of paper loaded in each tray, see Hardware
Guide.
❒ Be sure to set a paper type using the control panel. If you do not set it,
the printing result might not be proper.
❖ LCT
Plain Paper, Recycled Paper, Special Paper, Color Paper, Letterhead, Pre-
punched, Bond Paper, Preprinted
