Ricoh Aficio SP 8100DN [271/340] Setting up options
![Ricoh Aficio SP 8100DN [271/340] Setting up options](/views2/1064372/page271/bg10f.png)
Mac OS
259
8
C Click [Change] in [USB Printer Selection].
D Select the model you are using in [Select a USB Printer:], and then click [OK].
E Click [Create].
F Enter the printer name, and then click [Save].
The printer icon appears on the desktop.
G Quit Desktop Printer Utility.
Setting Up Options
A On the [Apple] menu, click [Chooser].
B Click the Adobe PS icon.
C In the [Select the PostScript Printer:] list, click the name of the printer you want
to use, and then click [Setup...].
D Click [Configure].
A list of options appears.
E Select the option you want to set up, and then select an appropriate setting
for it.
F Click [OK].
The list of options closes.
G Click [OK].
The [Chooser] dialog box appears.
H Close the [Chooser] dialog box.
Note
❒ If the option you want to select is not displayed, PPD files may not be set
up correctly. To complete the setup, check the name of the PPD file dis-
played in the dialog box.
