Making Printer Settings Using the Control Panel
146
4
•AppleTalk
Active, Not Active
Note
❒ Default: Active
❖ Ethernet Speed
You can select the network speed to operate the printer.
•Auto Select
• 10Mbps Half D.
• 10Mbps Full D.
• 100Mbps Half D.
• 100Mbps Full D.
Note
❒ Default: Auto Select
❖ LAN Type
You can select Ethernet or IEEE 802.11b for LAN Type.
This menu appears only when the optional 802.11 interface unit and the
optional SDRAM module are installed.
•Ethernet
• IEEE 802.11b
Note
❒ Default: Ethernet
❖ IEEE 802.11b
You can make settings for wireless LAN. This menu appears only when the
optional 802.11b interface unit and the optional SDRAM module are installed.
❖ Comm. Mode
You can select the transmission mode for IEEE 802.11b.
• 802.11 Ad hoc
• Infrastructure
•Ad hoc
Note
❒ Default: 802.11 Ad hoc
❒ Comm. Mode can also be set using a Web Image Monitor. For details,
see Web Image Monitor Help.
❖ Channel
You can select channels: 1-13 (metric version)/1-11 (inch version).
Note
❒ Default: 11 (metric and inch version)
