Monitoring and Configuring the Printer
186
5
❖ Current interface priority configuration display
msh> autonet priority
❖ Interface priority configuration
msh> autonet priority “interface_name”
• You can give interface's AutoNet parameter priority.
• Priority settings are available when multiple interfaces are installed.
• wlan can be specified only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
Note
❒ If an interface is not selected, the current interface connection settings remain
in effect.
Reference
For details about AutoNet, refer to autonet parameters.
bonjour(rendezvous)
Use the “bonjour(rendezvous)” command to display bonjour(rendezvous)-re-
lated settings.
❖ View settings
Bonjour settings are displayed.
msh> bonjour
❖ Bonjour service name setting
You can specify the bonjour service name.
msh> bonjour cname “computer name”
• The computer name can be entered using up to 63 alphanumeric charac-
ters.
❖ Bonjour Installation location information setting
You can enter information about the location where the printer is installed.
msh> bonjour location “location”
• Information about location can be entered using up to 32 alphanumeric
characters.
Interface name Interface configured
ether Ethernet interface
wlan IEEE 802.11b interface
