Remote Maintenance by telnet
187
5
❖ Setting order of priority for each protocol
•diprint
msh> bonjour diprint [0–99]
•lpr
msh> bonjour lpr [0–99]
•ipp
msh> bonjour ipp [0–99]
You can specify the order of priority for “diprint”, “lpr”, and “ipp”. Smaller
numbers indicate higher priority.
❖ IP TTL setting
msh> bonjour ip ttl {1-255}
You can specify the IP TTL (the number of routers a packet can pass through).
Note
❒ The default is 255.
❖ Resetting the computer name and location information
You can reset the computer name and location information.
msh> bonjour clear {cname | location}
•cname
Reset the computer name. The default computer name will be displayed
when the computer is restarted.
•location
Reset the location information. The previous location information will be
deleted.
❖ Interface configuration
msh> bonjour linklocal “interface_name”
• If many types of interface are installed, configure the interface that com-
municates with linklocal address.
• If you do not specify an interface, the Ethernet interface is automatically se-
lected.
• wlan can be specified only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
Interface Interface configured
ether Ethernet interface
wlan IEEE 802.11b interface
