Ricoh Aficio SP 8100DN [248/340] Monitoring and configuring the printer
![Ricoh Aficio SP 8100DN [248/340] Monitoring and configuring the printer](/views2/1064372/page248/bgf8.png)
Monitoring and Configuring the Printer
236
5
SMTPC: username or password wasn’t cor-
rect. [response code] (information)
Connection to the SMTP server failed, because
the specified SMTP user name is incorrect, or
the specified SMTP password is incorrect.
Check the SMTP user name and password.
Snmp over IPv4 is ready Communication over IPv4 with snmp is avail-
able.
Snmp over IPv6 is ready. Communication over IPv6 with snmp is avail-
able.
Snmp over IPX is ready. Communication over IPX with snmp is availa-
ble.
snmpd start. The snmpd service has started.
started. The direct print service has started.
Started. The bonjour (rendezvous) function is enabled.
Terminated. The bonjour (rendezvous) function is disabled.
The print server received error <error
number> during attempt to log in to the net-
work. Access to the network was denied. Ver-
ify that the print server name and password
are correct.
Login to the file server failed. The print server
is not registered or a password is specified.
Register the print server without specifying a
password.
trap account is unavailable. v3Trap cannot be sent. This could be because
the Trap destination account is different from
the account specified by the printer.
usbd is disable. Plug and Play function and printing is disa-
bled because usbd is disabled in the security
mode.
Enable usbd in the security mode.
WINS name registration: No response to serv-
er<WINS server address>
There was no response from the WINS server.
Check the correct WINS server address is en-
tered. Alternatively, check the WINS server is
functioning properly.
WINS wrong scopeID=<Scope ID> An invalid scope ID was used. Use a valid
scope ID.
wpa authentication Failed WPA authentication failed. Check the WPA
configuration.
wpa authentication started WPA authentication has started.
wpa IEEE802.1X started WPA authentication has started.
wpa connecting to authenticator WPA is connecting to authenticator.
wpa link up WPA key exchange has finished, and commu-
nication has been terminated.
wpa probe response doesn’t have IE. WPA probe response does not have IE.
wpa success authenticated WPA authentication was successful.
wpa success key received WPA key reception was successful.
Message Problem and solutions
