When Using Windows Terminal Service/MetaFrame
317
9
When Using Windows Terminal
Service/MetaFrame
The following explains how to use Windows Terminal Service and Maintenance.
Operating Environment
The following operating systems and MetaFrame versions are supported.
❖ Windows NT Server 4.0 Terminal Server Edition with SP6 or higher
• MetaFrame 1.8 SP3/FR1+SP3/SP4
• MetaFrame XP 1.0 SP1/SP2/FR1
❖ Windows 2000 Server/Advanced Server
• MetaFrame 1.8 SP3/FR1+SP3/SP4
• MetaFrame XP 1.0 SP1/SP2/SP3/SP4/FR1/FR2/FR3
• MetaFrame Presentation Server 3.0
• Citrix Presentation Server 4.0
❖ Windows Server 2003
• MetaFrame XP 1.0 FR3
• MetaFrame Presentation Server 3.0
• Citrix Presentation Cerver 4.0
Supported Printer Drivers
❖ When Windows Terminal Service is operating
•PCL printer drivers
• PostScript 3
•RPCS drivers
Note
❒ Some RPCS printer driver functions do not work if Windows Terminal Serv-
ice is installed.
