Menu Chart
123
4
Note
❒ [Auto Del. Temp], [Auto Del.Stored], and [Spool Printing] appear when the op-
tional hard disk is installed.
❒ [RAM Disk] will not appear when the optional hard disk is installed.
❖ Host Interface
Note
❒ [IEEE 802.11b] appears when the optional IEEE 802.11b interface unit and
the optional SDRAM module are installed.
❖ PCL Menu
Rotate 180 Deg.
Energy Saver
Auto Reset Time
Auto Del. Temp
Auto Del.Stored
Memory Usage
Unit of Measure
Edge Smoothing
Toner Saving
Spool Printing
Letterhead Mode
Bypass Priority
Auto Tray SW
RAM Disk
Notify by Email
Menu
I/O Buffer
I/O Timeout
Network Setup
IEEE 802.11b
Menu
Orientation
Form Lines
Font Source
Font Number
Menu
