Making Printer Settings Using the Control Panel
138
4
❖ Blank Pages
You can specify whether or not to print blank pages.
•Do not print
•Print
Note
❒ Default: Print
❖ Output Tray
Specify the output tray that is selected by priority if the output tray is not ex-
plicitly specified.
❖ Job Separation
This appears on the menu only when the optional finisher is installed.
Specify whether to perform shift for each job on the output tray equipped
with the shift function.
•On
•Off
Note
❒ Default: Off
❖ Rotate 180 Deg.
You can select whether or not to rotate the image by 180 degrees when print-
ing.
•On
•Off
Note
❒ Default: Off
❖ Energy Saver
You can specify the number of minutes Energy Saver mode is applied.
❖ E. Saver On/Off
You can specify whether or not to switch Energy Saver.
•On
•Off
Note
❒ Default: On
❒ When the printer switches to Energy Saver mode, the Power indicator
is unlit, but the Online indicator remains lit.
