Ricoh Aficio SP 8100DN [226/340] Configuration
![Ricoh Aficio SP 8100DN [226/340] Configuration](/views2/1064372/page226/bge2.png)
Monitoring and Configuring the Printer
214
5
Note
❒ You can use this command only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
wins
Use the “wins” command to configure WINS server settings.
❖ Viewing settings
msh> wins
• If the IPv4 address obtained from DHCP differs from the WINS IPv4 ad-
dress, the DHCP address is the valid address.
❖ Configuration
msh> wins “interface_name” {on | off}
• {on} means “active” and {off} means “inactive”.
• Be sure to specify the interface.
• wlan can be specified only when the IEEE 802.11b interface unit and the
optional SDRAM module are installed.
username2 “character string” You can specify the phase 2 username for
EAP-TTLS/PEAP phase 2 authentication.
Usable characters: ASCII 0x20-0x7e (31
bytes) other than “@”. The default is blank.
domain “character string” You can specify the login domain name for
the Radius server.
Usable characters: ASCII0x20-0x7e (31 bytes)
other than “@”. The default is blank.
password “character string” You can specify the login password for the
Radius server.
Usable characters: ASCII 0x20-0x7e(128
bytes). The default is blank.
srvcert {on|off} You can set the server certificate. The default
is “off”.
imca {on|off} You can enable or disable the certificate
when the intermediate certificate authority is
present. The default is “off”.
srvid “character string” You can set the server ID and subdomain of
the certificate server.
Interface name Interface configured
ether Ethernet interface
wlan IEEE 802.11b interface
Parameter Value configured
