Ricoh Aficio SP 8100DN [190/340] On demand e mail notification
![Ricoh Aficio SP 8100DN [190/340] On demand e mail notification](/views2/1064372/page190/bgbe.png)
Monitoring and Configuring the Printer
178
5
On-demand E-mail Notification
A Click [Configuration] in the menu area, and then click [On-demand E-mail Notifi-
cation] on the [Device Settings] area.
The dialog box for making notification settings appears.
B Make the following settings:
• Notification Subject: Enter a text string to be added to the subject line of re-
turn e-mails.
• Items in Notification Message column: You can set this according to your
needs, for example, the printer's location, service representative contact in-
formation.
• Items in the Access Restriction to Information column: Select whether to
restrict accesses based on a specific category of information.
• Items in the Receivable E-mail Address/Domain Name Settings column:
Enter an e-mail address or domain name to use for requesting information
by e-mail and to receive its return e-mail.
C Click [OK].
D Click [Logout].
E Quit Web Image Monitor.
