Appendix
304
9
Note
❒ If you apply for two certificates simultaneously, the certificate authority
may not appear in the certificates. When you install these certificates, be
sure to take notes of the certificate contents and the order in which the cer-
tificates were installed.
❒ Using Web Image Monitor, you can create the contents of the server certif-
icate but you cannot send the application.
❒ Click [Cancel Request] to cancel the request for the server certificate.
Reference
For details about the displayed items and selectable items, see Web Image
Monitor Help.
When the optional hard disk, optional SDRAM module or data storage
card is not installed, you can not operate. Then “An unexpected error has
occurred.” appears.
Installing the Server Certificate (Certificate Issued by a Certificate Authority)
Install the server certificate using Web Image Monitor.
This section explains the use of a certificate issued by a certificate authority as
the server certificate.
Enter the server certificate contents issued by the certificate authority.
A Log on to Web Image Monitor in the administrator mode.
B Click [Configuration], and then click [Device Certificate] in the “Security” area.
The [Device Certificate] page appears.
C Click [Install].
D Enter the contents of the server certificate.
In the Device Certificate Request box, enter the contents of the server certifi-
cate received from the certificate authority.
E Click [OK].
[Installed] appears under [Certificate Status] to show that a server certificate for
the printer has been installed.
F Quite Web Image Monitor.
Reference
For details about the displayed items and selectable items, see Web Image
Monitor Help.
