Protection Using Encryption
307
9
SNMPv3 Encryption
This can be specified by the administrator.
When using SmartDeviceMonitor for Admin or another application to make
various settings, you can encrypt the data transmitted.
By making this setting, you can protect data from being tampered with.
Specify the SNMPv3 encrypted communication mode using Web Image Moni-
tor.
A Log on to Web Image Monitor in the administrator mode.
B Click [Configuration].
C Click [Network Security] in the “Security” area.
D Click [Ciphertext Only] in the “Permit SNMPv3 Communication” area in the
“SNMP” area, and then click [OK].
E Quit Web Image Monitor.
Note
❒ To use SmartDeviceMonitor for Admin for encrypting the data for speci-
fying settings, you need to specify the administrator’s [Encryption Password]
setting and [Encryption Key:] in [SNMP Authentication Information] in SmartDe-
viceMonitor for Admin, in addition to specifying [Permit SNMPv3 Communi-
cation] on the printer.
❒ If administrator’s [Encryption Password] setting is not specified, the data for
transmission may not be encrypted or sent.
Reference
For details about specifying [Encryption Key:] in SmartDeviceMonitor for
Admin, see the SmartDeviceMonitor for Admin Help.
