Using a Printer Server

250

P Set up the network connection to a print server. Select a context specified

using NIB Setup Tool, and then click [Create] on the [Object] menu.

Q In the [Class of new object] box, click [Print Server], and then click [OK]. For

NetWare 5, click [Print Sever (Non NDPS)].

R In the [Print Server Name] box, enter the print server name.

S Select the [Define additional properties] check box, and then click [Create].

T Assign the printer to the created print server. Click [Assignments], and then

click [Add] in the [Assignments] area.

U In the [Available objects] box, click the queue you created, and then click [OK].

V In the [Printers] area, click the printer you assigned, and then click [Printer

Number].

W Enter the printer number, and then click [OK]. Check the settings, and then

click [OK].

X Start the print server by entering the following from the console of the Net-

Ware server.

If the print server is in operation, quit and restart it.

❖ To exit

CAREE: unload pserver

❖ To start

CAREE: load pserver “print_server_name”

Y Enter the printer server name as the context name, and then press the {OK}

key.

Z Select the printer name on the context menu, and then press the {OK} key.

Setting up using Web Image Monitor

A Start Web Image Monitor.

B Click [Login].

A dialog box for entering the [Login User Name] and [Login Password] appears.

C Enter the login user name and password, and then click [Login].

For details about the login name and password, consult your administrator.

D Click [Configuration] in the left area, and then click [NetWare Print Settings].

E Confirm the settings, and then click [OK].

Configuration is now complete. Wait several minutes before restarting Web

Image Monitor.

F Click [Logout].
