ESIE 05-07 Piping Layout
Part 1 – System Outline 1–101
3
1
4
5
Components
refrigeration side
The table below describes the main components of the refrigeration circuit on the refrigeration side.
No. Component Function / remark
1 Compressor All compressors are semi-hermetic screw compressors with
step less capacity control.
3 Air-heat exchanger
(condenser)
The air-heat exchanger is of the cross fin coil type. Hi-X-tubes
and PE coated waffle louvre fins are used. The air is discharged
upwards.
4 Fan Direct driven single speed motor.
6 Low-pressure
transmitter and High
pressure transmitter
The Low and high pressure transmitter are used to gain
information in order to perform some controls and also act as
safety.
7 High-pressure switch This switch acts as a circuit safety.
P Activation at 25 bar
P Manual reset at HP-Switch
8 Strainer This strainer prevents dirt particles from entering the solenoid
valve of the liquid injection.
10 Low-pressure service
port
The low-pressure service port is used to connect a low-pressure
gauge.
11 High-pressure service
port
The high-pressure service port is used to connect a
high-pressure gauge.
12 Serviceport Serviceport.
13 Liquid stop valve The liquid stop valve is used as shut-off valve in case of a
pump-down.
14 Suction stop valve
(optional)
This suction stop valve can be used in combination with the
discharge stop valve to seperate the compressor from the
system (for examble: maintenance).
17 Safety valve The safety valves prevent pressure above 28 bar.
18 Drier + charge valve The replaceable filter drier will keep the refrigerant system dry. It
is equipped with a 3/8”charge valve.
20 Discharge stop valve This stop valve is used during pump down and service work in
combination with liquid stop valve or suction stop valve if
present (optional).
