General Outline ESIE 05-07
1–24 Part 1 – System Outline
3
11
4
5
1.13 Electrical Specifications: ERAP110~170MBYNN
Electrical
specifications
The table below contains the electrical specifications
Model
ERAP110MBYNN ERAP150MBYNN ERAP170MBYNN
Power supply
Phase
3N~
Frequency
50 Hz
Voltage
400 V
Voltage
tolerance
±10 %
Unit
Starting current
158 A 193 A 248 A
Nominal running
current
70A 84A 104A
Max. running
current
95 A 120 A 135 A
Recommended
fuses
3 x 125gL A 3 x 160gL A
Fans
Phase
1~
Voltage
230 V
Max. running
current
4 x1.9 A 4 x3.1 A
Compressor
Phase
3~
Voltage
400+/-10% V
Starting current
= Starting current of the unit
Nom. running
current
62 A 70 A 90 A
Max. running
current
87 A 106 A 121 A
Starting method
Star-Delta
Control circuit
Phase
1~
Voltage
230/24 AC (supplied by factory installed tranformers)
Recommended
fuses
Factory installed
Liquid line
solenoid valves
(Y15..16S/
Y25..26S)
2 x (16.1 VA -70 mA) inrush current = 130 mA
Capacity sole-
noid valves
(Y11S)
1 x (16.1 VA -70 mA) inrush current = 130 mA
ESIE05-07.book Page 24 Wednesday, October 11, 2006 10:42 AM
