The Functional Controller for DICN ESIE05-07
2–106 Part 2 – Functional Description
3
1
2
4
5
3.22 Changeable Digital Outputs
Introduction This function is the same as for standalone units.
Range of
application
Remark: (*) DO1 for CO, HR and ER units is fixed to evaporator heatertape, therefore it will not be
visible in the service menu.
Functions overview
Input
Parameter
on controller
Air-cooled Water-cooled Condenser-less
EWAP
/EWAD
EWTP EWWD EWLD
CO HR HP RC
DO12 DO1 O (*) O (*) O O
DO13 DO2 O O O O
Possible functions Air-cooled Evaporator-less Water-cooled Condenser-less
EWAP/
EWAD
EWTP ERAP EWWD EWLD
CO HR CA HP RC
0. None (open) O O O O O
1. 1 (closed) O O O O O
2. 2
nd
evaporator
pump
OOO O O
3. Condenser pump -- -- -- O --
4. 100% capacity O O O O O
5. free cooling O O -- -- O
6. general operation O O O O O
7. Reversing valve -- -- -- O --
8. Evaporator
heater-tape
OOO -- O
9. HR condenser
pump
-- O -- -- --
