The Digital Controller For Large chillers ESIE 05-07
2–114 Part 2 – Functional Description
3
1
2
4
5
4.5 Menu Overview
Introduction This chapter gives an overview of the screens provided by the different menus.
Appears when connected
to power supply.
Not visible on remote terminal
because all menus are directly
accessible with
the different menu keys.
Initial Test Main menu Readout menu
Setpoint menu
User settings menu
Service menu
Timers menu
History menu
Info menu
Input/Output menu
User password menu
Network menu
Safety menu
Cooling/heating menu
