ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–113
3
1
4
5
DICN option DICN = Daikin Integrated Chiller Network
Also referred to as master-slave system
Basic principles:
P No ER-units in a DICN-system
P Possible to combine all air-cooled (including heat-recovery) in one DICN-system
P Possible to combine all water-cooled in one DICN-system.
P Possible to combine all condensers-less in one DICN-system.
P It is possible to combine up to max 4 units in one DICN-system.
P It is not possible to combine water-cooled, air-cooled or condenser-less in one DICN.
WATER-COOLED
Unit name
HP compressor
combination
Nr of
EEV
Controller
EWLD
Remote
Condenser:
R134a
EWLD120MBYNN 40HP 0
pCO
2
medium
controller
EWLD170MBYNN 60HP 0
EWLD240MBYNN 80HP 1
EWLD260MBYNN 100HP 1
EWLD340MBYNN 60HP&60HP 0
pCO
2
large con-
troller
EWLD400MBYNN 80HP&60HP 1
EWLD480MBYNN 80HP&80HP 2
EWLD500MBYNN 100HP&80HP 2
EWLD540MBYNN 100HP&100HP 2
ERAP
Condensing
units: R407C
ERAP110MBYNN 40HP 0
pCO
2
medium
controller
ERAP150MBYNN 50HP 0
ERAP170MBYNN 60HP 0
EWTP
Heat
recovery:
R407C
EWTP110MBYNN 40HP 0
pCO
2
medium
controller
EWTP140MBYNN 50HP 0
EWTP160MBYNN 60HP 0
EWTP200MBYNN 80HP 0
EWTP280MBYNN 100HP 0
EWTP340MBYNN 120HP 0
EWTP400MBYNN 80HP&80HP 0
pCO
2
large
controller
EWTP460MBYNN 100HP&80HP 0
EWTP540MBYNN 100HP&100HP 0
ESIE05-07.book Page 113 Wednesday, October 11, 2006 10:42 AM
