ESIE05-07 The Functional Controller for DICN
Part 2 – Functional Description 2–85
3
2
4
5
1
3.4 On/Off Management
Overview The table below gives an overview of the status of the unit in different situations.
Remark: If a remote ON/OFF switch is present this switch must be set to "ON" before the unit can
start up.
MS Option = yes (network unit)
MS Option = no
(standalone unit)
NORMAL or STANDBY DISCONN.ON/OFF
On/Off status Equal for all units that are in
"NORMAL/STANDBY" mode
Dedicated to this
unit only.
Dedicated to this
unit only.
Changing the
On/Off status
on the
controller
When you push the ON/OFF button
on a unit that is in
"NOMAL/STANDBY" mode the sta-
tus (ON/OFF) will be transferred to
all the other units in
"NORMAL/STANDBY" mode
The status (On/Off)
is dedicated to this
unit only.
The status
(On/Off) is dedi-
cated to this unit
only.
Changing the
On/OF status
remotely
Into the service menu of the master,
you can select a changeable Digital
Input as "Remote On/Off"
Into the service
menu of that unit,
you can select a
changeable
Digital Input as
"Remote On/Off"
Into the service
menu of that unit,
you can select a
changeable Dig-
ital Input as
"Remote On/Off"
Remark:
P If the master is "DISCONN.ON/OFF" then the DI will change the On/Off status
of the master & all the units with "NORMAL/STNADBY" mode.
P If a slave (=not the master) is "NORMAL/STNADBY" and the DI= "Remote
On/Off" then the DI of that slave will not change the On/Off status of the unit
&all the "NORMAL/STNADBY" units.
ESIE05-07.book Page 85 Wednesday, October 11, 2006 10:42 AM
