The Digital Controller For Large chillers ESIE 05-07
2–112 Part 2 – Functional Description
3
1
2
4
5
4.3 Start/Stop, Cool/Heat and Temperature settings
Power on P The initialization takes 10 seconds
P The controller automatically goes to the menu overview.
Remote start/stop The procedure to start or stop the unit depends on the settings of the remote start/stop.
Remark: The remote start/stop is field supply.
How to start or stop
How to cool or heat To change from cooling to heating (or visa versa) you have to enter the Cooling/Heating menu through
the main menu.
Emergency stop In case of an emergency: switch off the unit by pushing the emergency button.
Temperature
setting
To adjust the inlet or outlet water temperature, go to the Set Points menu through the main menu.
Remark To prevent the unit from stopping at 100% the unit will always load-down to 12% and operate at this
capacity for a couple of seconds before shutting down.
Local key Remote Switch Unit
o LED
ON ON ON ON
ON OFF OFF Flashing
OFF ON OFF OFF
OFF OFF OFF OFF
ESIE05-07.book Page 112 Wednesday, October 11, 2006 10:42 AM
