Daikin EWAP460MBYN [356/452] Safety menu

The Digital Controller For Large chillers ESIE 05-07

2–160 Part 2 – Functional Description

4.17 Safety Menu

Introduction The safeties menu is only accessible, by pressing the p when a unit/circuit/network safety is

activated. The kind of safety will be displayed with a code, followed by its description.

The safeties menu is linked to the history screen. By pushing the q key when in the safety menu

you jump to the history menu where, along with the basic information, more detailed data screens can

be consulted, by pressing the

q key again.

Remark: In the service menu it is possible to choose the password that will be requested to be able

to reset the safeties. This can be either the service either the user password. When one of these

passwords is selected in the service menu, it will be requested to enter that password before the safety

can be reset. Default the user password (1234) is needed to reset the errors.

Screen 1a

Screen 1b When the error is solved the p key starts blinking and it is possible to reset the safety by pressing

the p key.

Line n° Display Description

1a UNIT WARNING

UNIT SAFETY

CIRCUIT SAFETY

NETWORK SAFETY

CIRCUIT WARNING

Indicates if you have a unit, circuit or network

safety or warning (Not possible to reset, safety is

still present)

2 XXX:XXXXXXXXXXXX Indicates the safety code and its description.

Line n° Display Description

1b RESET UNIT WARNING

RESET UNIT SAFETY

RESET CIRCUIT SAFETY

RESET NETW SAFETY

RESET CIRC WARNING

After solving the problem, the alarm key starts

blinking and the display indicates that resetting is

possible.(possible to reset)

2 XXX:XXXXXXXXXXXX Indicates the safety code and its description.
