ESIE05-07 Test Run and Operation Data

Part 4 – Commissioning and Test Run 4–23

2.5 Test Run and Operation Data for EWLD120~540MBYNN

Pressures The table below contains the measurable pressures.

Temperatures The table below contains the measurable temperatures.

Voltages The table below contains the measurable voltages.

Currents The table below contains the currents and used fuses.

Measurement Value

Suction pressure

depending on working conditions

Discharge pressure

Maximum water pressure 10 bar

Measurement Value

Leaving water temperature

P Standard: 4 – 16°C

P With glycol: -10 – 16°C

P Heating: 30 – (49 till 62°C) depending on the

evaporator leaving water

Temperature difference at the air side 10 – 15°C

Temperature difference at the water side 3 – 8°C

Discharge temperature 80 – 120°C

Approach temperature

(evap leaving water temp - sat. temp)

5 – 8°C (for MOW of 4°C)

for glycol units this can be > 8°C

Measurement Value

Power supply voltage Within ± 10% of the rated voltage

Phase imbalance Within ± 2% of the rated voltage

Control circuit voltage 230 V AC for main electromagnetic switches

24 V DC for the controllers

Unit Nominal current Maximum current Fuses

EWLD120MBYNN 48 A 76 A 3 x 100 gL A

EWLD170MBYNN 78 A 120 A 3 x 160 gL A

EWLD240MBYNN 108 A 191 A 3 x 224 gL A

EWLD260MBYNN 118 A 199 A

EWLD340MBYNN 156 A 240 A 5 x 200 gL A

EWLD400MBYNN 186 A 311 A 3 x 200 gL A

+ 3 x 250 gL A
