The Functional Controller for DICN ESIE05-07
2–86 Part 2 – Functional Description
3
1
2
4
5
3.5 Thermostat Control
Overview When connected in DICN the regulation mode (inlet/outlet) is transferred to all units with MS Option
set to "YES".
Overview of the
possibilities
MS Option = yes (network unit)
MS Option = no
(standalone unit)
NORMAL or STANDBY DISCONN.ON/OFF
Inlet/Outlet
mode
Equal for all units Equal for all units Dedicated to
this unit only.
Changing to
Inlet/Outlet
When you change the Inlet/outlet
mode in a unit. Status is transferred
to all other units.
Except units that are in ("DIS-
CONN.ON/OFF" mode and manual
mode).
When you change the
Inlet/outlet mode in a
unit. Status is trans-
ferred to all other
units. Except units
that are in ("DIS-
CONN.ON/OFF"
mode and manual
mode).
When you
change the
Inlet/outlet
mode in that
unit. No status is
transferred to
other units.
Air-cooled cool-
ing only
Evaporator-less Water-cooled
Condenser
-less
EWAP/
EWAD
EWTP ERAP EWWD EWLD
CO HR CA HP RC
Cooling
mode
Inlet
water
step
XX X X
Outlet
water
step
XX X X
Thermo-
stat
X
External
Analog
signal
XX X X
Heating
mode
Inlet
water
step
X
External
analog
signal
X
Double
thermo-
stat mode
Inlet
water
step
X
External
analog
signal
X
Manual Controll X X X X X
ESIE05-07.book Page 86 Wednesday, October 11, 2006 10:42 AM
