4.8 Set Points Menu
Screen 1: password Depending on the settings in the user settings menu explained further on, the system may require the
user password to enter the screens in this menu.
This screen will only appear if a password is required.
Remark: The units leave the factory with the user password set to "1234". This user password can be
modified in the user password menu.
Screen 2: This menu allows you to set the inlet/ outlet water temperature of the evaporator/condenser of circuit
1 and 2. These set points will not be active in the Manual Control Mode.
Not all lines are visible. The type of unit and the operating mode determine which lines are visible:
P Line 1, 2, 3, 4: Water and air-cooled units: Cooling mode(Inlet/Outlet/Manual).
P Line 1a, 2a: only for water-cooled units: Heating mode(Inlet/Manual).
P Line 1, 2, 1a, 2a: only for water-cooled units: Double thermostat (Inlet/manual).
P Line 3a, 4a: only for ER units (Thermostat setpoint).
A ">" symbol is displayed in front of the active setpoint in this screen.
Remark: You can select setpoint 1 or 2 with a digital input from a switch. In the service menu you can
select which digital input you want to use for this.
Line n° Display Description
1 ENTER PASSWORD Screen title
3 PASSWORD: 0000 Enter the correct password
Line n° Display Description Default value Lower limit
Upper
limit
1 INLSETP1 E Inlet water temp. set
point 1 evaporator
12.0 °C MOW+3°C 23°C
1a INLSETP1 C Inlet water temp. set
point 1 Condenser
12.0 °C 15°C 50°C
2 INLSETP2 E Inlet water temp. set
point 2 evaporator
12.0 °C MOW+3°C 23°C
2a INLSETP2 C Inlet water temp. set
point 2 Condenser
12.0 °C 15°C 50°C
3 OUTLSETP1 E Outlet water temp. set
point 1 evaporator
7.0 °C MOW 16°C
3a SETPOINT 1 Temp. setpoint 1 for
ER units
7.0 °C MOW 16°C
4 OUTLSETP2 E Outlet water temp. set
point 2 evaporator
7.0 °C MOW 16°C
4a SETPOINT 2 Temp. setpoint 2 for
ER units
7.0 °C MOW 16°C
