The Digital Controller For Large chillers ESIE 05-07
2–158 Part 2 – Functional Description
3
1
2
4
5
4.15 Network Menu
The network menu is only accessible when MS OPTION is set to "YES" in the service menu.
Screen 1 Line2, 3, 4 only visible if MSOption = Yes
Line 4 is only visible if in user settings menu the control setting mode is "outlet water setpoint".
An extra temperature sensor must be installed to measure the mixed outlet water temperature.
Screen 2
Line n° Display Description Possible settings
1NETWORK
2 XXXXXXX Gives the setpoint you selected to
use ( usersettings menu and dual
setpoint if selected )
INLSETP1(2) E
OUTSETP1(2) E
INLETSP1(2) C
SP1(2) E: C:
3 INL WATER E Inlet temperature of the inlet water
on the master unit.
°C
4 OUTL WATER E Gives the temperature of the
mixed outlet water temperature.
°C
Line n° Display Description Possible settings
1.1 ¨M: Displays status of Master
(as selected in user settings menu)
NORMAL/STANDBY/
DISCONN/SAFETY
1.2 ST: Displays the capacity of the master
2.1 SL1: Displays status of the slave
(as selected in user settings menu)
NORMAL/STANDBY/
DISCONN/SAFETY
2.2 ST: Displays the capacity of the slave1
3.1 SL2: Displays status of the slave
(as selected in user settings menu)
NORMAL/STANDBY/
DISCONN/SAFETY
3.2 ST: Displays the capacity of the slave2
4.1 SL3: Displays status of the slave
(as selected in user settings menu)
NORMAL/STANDBY/
DISCONN/SAFETY
4.2 ST: Displays the capacity of the slave3
ESIE05-07.book Page 158 Wednesday, October 11, 2006 10:42 AM
