ESIE 05-07 General Outline
Part 1 – System Outline 1–19
3
1
4
5
1.10 Electrical Specifications: EWAD120~340MBYNN
Electrical
specifications
The table below contains the electrical specifications.
Notes 1. Nominal cooling capacity at Eurovent conditions: Evaporator 12°C/7°C; ambient 35°C.
2. Nominal cooling power input at Eurovent conditions: Evaporator 12°C/7°C; ambient 35°C.
Model
EWAD
120MBYNN
EWAD
150MBYNN
EWAD
170MBYNN
EWAD
240MBYNN
EWAD
300MBYNN
EWAD
340MBYNN
Power supply
Phase
3N~
Frequency
50 Hz
Voltage
400 V
Voltage
tolerance
±10 %
Unit
Starting current
172 A 193 A 250 A
172 A
193 A 250 A
Nominal running
current
67.6 A 87.4 A 109 A 135 A 175 A 219 A
Max. running
current
83.6 A 101 A 140 A 167 A 203 A 281 A
Recommended
fuses
3 x 100gL A 3 x 125gL A 3 x 160gL A 3 x 200gL A 3 x 250gL A 3 x 300gL A
Fans
Phase
1~
Voltage
230 V
Max. running
current
4 x1.9 A 4 x3.1 A 8 x 1.9 A 8 x 3.1 A
Compressor
Phase
3~
Voltage
400+/-10% V
Starting current
= Starting current of the unit
Nom. running
current
60 A 75 A 97 A 2 x 60 A 2 x75 A 2 x 97 A
Max. running
current
76 A 89 A 128 A 2 x 76 A 2 x 89 A 2 x128 A
Starting method
Star-Delta
Control circuit
Phase
1~
Voltage
230/24 AC (supplied by factory installed tranformers)
Recommended
fuses
Factory installed
Crankcase
heater (E1/2HC)
1 x (150 W -0.65 A) 2 x (150 W -0.65 A)
Liquid line
solenoid valves
(Y15..16S/
Y25..26S)
2 x (16.1 VA -70 mA) inrush current = 130 mA
Capacity sole-
noid valves
(Y11/Y21)
1 x (16.1 VA -70 mA) inrush current = 130 mA 2 x (16.1 VA -70 mA) inrush current = 130 mA
