Wiring Layout ESIE 05-07
1–120 Part 1 – System Outline
3
11
4
5
P 2) Point to point: A gateway can be connected to the BMS making use of the RS232 connection
Note: BACnet is only possible in point to point setup and with a maximum of 8 address cards per
gateway.
P Gateway used for modbus gateway: EKBMSBNA / EKBMSMBA
P Address card EKAC200A should be used in each unit.
P When A DICN (master / slave) is connected to a BMS system, you only require an address card in
the master unit. When you require a full read-out of all parameters from the slave units, then all
slaves should have an address card connected to the gateway.
Unit 1
Unit 2
Unit 3
Unit ..
BACnet gateway
or
Modus-Jbus
Max: 16 address cards
per Gateway for
Modbus-Jbus
Max: 8 address cards
per gateway for BAC
net
RS232 protocol
(point to point)
BMS system
BMS
Water supply
lights
elevators
Fig 3.Point to point connection
