ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–127
3
1
4
5
The table below describes the components of the switchbox for EWAD120~340MBYNN
Wiring diagram
symbol
Description
V1 V-meter for circuit 1-2
TR2 Transfo supply controller + digital inputs
TR1 Transfo control circuit
TCO1, TCO2, TCO3,
TCO4
Optocoupler (analog to Digital signal)
S13S Main isolator switch
S5E Emergency stop push button
R1P, R2P Reverse phase protector circuit 1, circuit 2
K7A, K8A Auxiliary relay for safety High Pressure circuit 1, circuit 2
K3A, K6A Auxiliary relay for discharge thermal protector circuit 1, circuit 2
K2A, K5A Auxiliary relay for compressor thermal protector circuit 1, circuit 2
K1A, K4A Auxiliary relay for safeties circuit 1, circuit 2
K17S, K18S Overcurrent relay for circuit 1, circuit 2
K9F, K12F Fancontactor for circuit 1, circuit 2
K8F, K11F Fancontactor for circuit 1, circuit 2
K7F, K10F Fancontactor for circuit 1, circuit 2
K3M, K6M Starcontactor for circuit 1, circuit 2
K2M, K5M Deltacontactor for circuit 1, circuit 2
K1M, K4M Linecontactor for circuit 1, circuit 2
F14B Fuse for fanmotor switchbox
F12B, F13B Fuse for fanmotor circuit 1, circuit 2
F10S, F11S Circuit breakers with fuses for circuit 1, circuit 2
F9B Fuse for secondary of TR2
F7B Fuse for secondary of TR1
F6B Fuse for primary of TR1
A1P PCB-Controller
A1, A2 Current tranfo / A-meter for circuit 1, circuit 2
A11P Expansion board controller
ESIE05-07.book Page 127 Wednesday, October 11, 2006 10:42 AM
