ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–139
Field supply
NOT possible as Option Possible as Option
Obligatory # ##
NOT Obligatory * **
No. Function / remark No. Function / remark
Y11S 12% capacity step for compressor circuit 1 K17S overcurrent relay for circuit 1
Y15S liquid injection valve of the compressor circuit 1 K9F fancontactor for circuit 1
Y16S liquid line solenoid valve circuit 1 K8F fancontactor for circuit 1
V1 ** V-meter for circuit 1 K7F fancontactor for circuit 1
TR1 transfo control circuit K1M linecontactor for circuit 1
TR2 transfo supply controller + digital inputs K2M deltacontactor for circuit 1
TC01..TCO2 optocoupler (Analog to Digital signal) K3M starcontactor for circuit1
S14PH high pressure switch circuit 1 J4 analogue output
S13S ## main isolator switch J12, J13, J14,
J15 J16, J17, J18
digital output
S8L flowswitch
S9L # contact that closes if the pump is working J5, J7, J8 digital input
S6S, S10S *
S11S, S12S
changeable switch for remote function (rem. start-stop, dual setpoint, enable / disable cap.
lim. 1 / 2 / 3 / 4)
J2, J3, J6 analogue input
J11 RS485 connection
S5E emergency stop push button J1 power supply
S3T discharge thermal protector circuit 1 H5P * changeable output
S1PH high pressure switch circuit 1 H3P * indication lamp operation compressor 1
R8T sensor for evaporator outlet water temperature DICN H2P * indication lamp alarm
R5T sensor for ambient temperature H1P * indication lamp general operation
R4T sensor for outlet water temperature F12B-F14B fuse for fanmotors circuit 1
R3T sensor for evaporator inlet water temperature F9B fuse for secondary of TR2
R1P reverse phase protector circuit 1 F8U surge proof fuse for A1P
R1F feedback resistance for circuit 1 F7B fuse for secondary of TR1
R1 auxiliary resistance for feedback F6B fuse for primary of TR1
Q1M thermal protector compressor motor circuit 1 F4U, F5U # fuses for evaporator heater
Q11F-Q14F thermal protectors fan motors circuit 1 F1U, F2U, F3U # main fuses
PE main earth terminal E3H evaporator heater circuit 1
M1S stepless capacity ctrl for compressor circuit 1 E1HC crankcase heater compressor circuit 1
M1C compressor motor circuit 1 C1..C3 capacitor
M11F-M14F fan motors circuit 1 B2P high pressure transmitter for circuit 1
K7A auxiliary relay for safety High Pressure circuit 1 B1P low pressure transmitter for circuit 1
K3A auxiliary relay for discharge thermal protector circuit 1 A1P PCB-controller
K2A auxiliary relay compressor thermal protector circuit 1 A1 ** current transfo / A-meter for circuit 1
K1A auxiliary relay for safeties circuit 1
