ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–151
Field supply
NOT possible as Option Possible as Option
Obligatory # ##
NOT Obligatory * **
No. Function / remark No. Function / remark
Y11S, Y21S 12% capacity step for compressor circuit 1, circuit 2 K17S, K18S overcurrent relay for circuit 1, circuit 2
Y15S, Y25S liquid injection valve of the compressor circuit 1, circuit 2 K9F, K12F fancontactor for circuit 1, circuit 2
Y16S, Y26S liquid line solenoid valve circuit 1, circuit 2 K8F, K11F fancontactor for circuit 1, circuit 2
V1 ** V-meter for circuit 1-2 K7F, K10F fancontactor for circuit 1, circuit 2
TR1 transfo control circuit K3M, K6M starcontactor for circuit1, circuit 2
TR2 transfo supply controller + digital inputs K1M, K4M linecontactor for circuit 1, circuit 2
TC01..TCO4 optocoupler (Analog to Digital signal) K2M, K5M deltacontactor for circuit 1, circuit 2
S14PH, S15PH high pressure switch circuit 1, circuit 2 J12..J18
J21,J22
digital output
S13S ## main isolator switch
S8L flowswitch J5,J7,J8,J19 digital input
S9L # contact that closes if the pump is working J4 analogue output
S6S, S10S *
S11S, S12S
configurable switch for remote function
(rem. start-stop, dual setpoint, enable / disable cap. lim. 1 / 2 / 3 / 4)
J2,J3,J6 analogue input
J11,J23 RS485 connection
S5E emergency stop push button J1 power supply
S3T, S4T discharge thermal protector circuit 1, circuit 2 H5P * changeable output
S1PH, S2PH high pressure switch circuit 1, circuit 2 H4P * indication lamp operation compressor 2
R8T sensor for evaporator outlet water temperature DICN H3P * indication lamp operation compressor 1
R7T sensor for mixed outlet water temperature H2P * indication lamp alarm
R5T sensor for ambient temperature H1P * indication lamp general operation
R3T sensor for evaporator inlet water temperature F12B, F13B fuse for fanmotors circuit 1, circuit 2
R1P, R2P reverse phase protector circuit 1, circuit 2 F10S, F11S circuit breakers with fuses for circuit 1, circuit 2
R1F, R2F feedback resistance for circuit 1, circuit 2 F9B fuse for secondary of TR2
R1, R2 auxiliary resistance for feedback F8U surge proof fuse for A1P
Q1M, Q2M thermal protector compressor motor circuit 1, circuit 2 F7B fuse for secondary of TR1
Q21F-Q24F thermal protectors fan motors circuit 2 F6B fuse for primary of TR1
Q11F-Q14F thermal protectors fan motors circuit 1 F4U, F5U # fuses for evaporator heater circuit 1, circuit 2
PE main earth terminal F1U, F2U, F3U # main fuses
M1S, M2S stepless capacity ctrl for compressor circuit 1, circuit 2 E3H, E4H evaporator heater circuit 1, circuit 2
M1C, M2C compressor motor circuit 1, circuit 2 E1HC, E2HC crankcase heater compressor circuit 1, circuit 2
M21F-M24F fan motors circuit 2 C1..C3 capacitor
M11F-M14F fan motors circuit 1 B2P, B5P high pressure transmitter for circuit 1, circuit 2
K7A, K8A auxiliary relay for safety High Pressure circuit 1, circuit 2 B1P, B4P low pressure transmitter for circuit 1, circuit 2
K3A, K6A auxiliary relay for discharge thermal protector circuit 1, circuit 2 A11P expansion board controller
K2A, K5A auxiliary relay compressor thermal protector circuit 1, circuit2 A1P PCB-controller
K1A, K4A auxiliary relay for safeties circuit 1, circuit 2 A1,A2 ** current transfo / A-meter for circuit 1, circuit 2
