ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–167
Field supply
NOT possible as Option Possible as Option
Obligatory # ##
NOT Obligatory * **
No. Function / remark No. Function / remark
Y11S, Y21S 12% capacity step for compressor circuit 1, circuit 2 K1A, K4A auxiliary relay for safeties circuit 1, circuit 2
Y15S, Y25S liquid injection valve of the compressor circuit 1, circuit 2 K17S, K18S overcurrent relay for circuit 1, circuit 2
Y16S, Y26S liquid line solenoid valve circuit 1, circuit 2 K9F, K12F fancontactor for circuit 1, circuit 2
Y1E,Y2E electronic expansion valve circuit 1, circuit 2 K8F, K11F fancontactor for circuit 1, circuit 2
X2A,X3A,X4A Connector 24,20,16pole to Main Switchbox K7F, K10F fancontactor for circuit 1, circuit 2
V2C-V5C ferrite for EEV K3M, K6M starcontactor for circuit1, circuit 2
V1F filter for EEV K1M, K4M linecontactor for circuit 1, circuit 2
V1 ** V-meter for circuit 1-2 K2M, K5M deltacontactor for circuit 1, circuit 2
TR1 transfo control circuit J12..J18 digital output
TR2 transfo supply controller + digital inputs J21,J22 digital output
TC01..TCO4 optocoupler (Analog to Digital signal) J5,J7,J8,J19 digital input
S14PH, S15PH high pressure switch circuit 1, circuit 2 J4 analogue output
S13S ## main isolator switch J2,J3,J6,J20 analogue input
S8L, S10L flowswitch circuit 1, circuit 2 J11,J23 RS485 connection
S9L, S11L # contact that closes if the pump is working J1 power supply
S6S, S10S *
S11S, S12S
configurable switch for remote function
(rem. start-stop, dual setpoint, enable/disable cap. lim. 1 / 2 / 3 / 4)
H1P * indication lamp general operation
H2P * indication lamp alarm
S5E emergency stop push button H3P * indication lamp operation compressor 1
S3T, S4T discharge thermal protector circuit 1, circuit 2 H4P * indication lamp operation compressor 2
S1PH, S2PH high pressure switch circuit 1, circuit 2 H5P, H6P* changeable output
R3T sensor for evaporator inlet water temperature F12B, F13B fuse for fanmotors circuit 1, circuit 2
R4T sensor for evaporator outlet water temperature circuit 1 F10S, F11S circuit breakers with fuses for circuit 1, circuit 2
R5T sensor for ambient temperature F9B fuse for secondary of TR2
R6T sensor for evaporator outlet water temperature circuit 2 F8U surge proof fuse for A1P
R7T sensor for mixed outlet water temperature F8B fuse for EEV Driver
R8T sensor for evaporator outlet water temperature DICN F7B fuse for secondary of TR1
R9T, R10T temperature sensor EEV for circuit 1 (A2P), circuit 2 (A3P) F6B fuse for primary of TR1
R1P, R2P reverse phase protector circuit 1, circuit 2 F1U, F2U, F3U # main fuses
R1F, R2F feedback resistance for circuit 1, circuit 2 F4U, F5U # fuses for evaporator heater circuit 1, circuit 2
R1, R2 auxiliary resistance for feedback F11U..F13U # main fuses
Q1M, Q2M thermal protector compressor motor circuit 1, circuit 2 F21U..F23U # main fuses
Q21F-Q24F thermal protectors fan motors circuit 2 F1R,F2R fuses for reverse phase protector circuit 1, circuit 2
Q11F-Q16F thermal protectors fan motors circuit 1 E1HC, E2HC crankcase heater compressor circuit 1, circuit 2
PE main earth terminal C11,C21 capacitor for capacity control
M1S, M2S stepless capacity ctrl for compressor circuit 1, circuit 2 B1P, B4P low pressure transmitter for circuit 1, circuit 2
M1C, M2C compressor motor circuit 1, circuit 2 B2P, B5P high pressure transmitter for circuit 1, circuit 2
M21F-M26F fan motors circuit 2 B3P,B6P low pressure transmitter for circuit 1 (A2P), circuit 2 (A3P)
M11F-M16F fan motors circuit 1 A1P PCB-controller
K7A, K8A auxiliary relay for safety High Pressure circuit 1, circuit 2 A1,A2 ** current transfo / A-meter for circuit 1, circuit 2
K3A, K6A auxiliary relay for discharge thermal protector circuit 1, circuit 2 A2P,A3P PCB-EEV Driver circuit1, circuit 2
