ESIE 05-07 Wiring Layout
Part 1 – System Outline 1–171
Field supply
NOT possible as Option Possible as Option
Obligatory # ##
NOT Obligatory * **
No. Function / remark No. Function / remark
Y11S 12% capacity step for compressor circuit 1 K3A auxiliary relay for discharge thermal protector circuit 1
Y15S liquid injection valve of the compressor circuit 1 K17S overcurrent relay for circuit 1
Y16S liquid line solenoid valve circuit 1 K1M linecontactor for circuit 1
V1 ** V-meter for circuit 1 K2M deltacontactor for circuit 1
TR1 transfo control circuit K3M starcontactor for circuit1
TR2 transfo supply controller + digital inputs J1 power supply
TCO1,TCO2 optocoupler (Analog to Digital signal) J2, J3, J6 analogue input
S1PH high pressure switch circuit 1 J4 analogue input
S14PH high pressure switch circuit 1 J5, J7, J8 digital input
S13S ## main isolator switch J11 RS485 connection
S5E emergency stop push button J12,J13,J14,J15
J16,J17,J18
digital output
S8L flowswitch circuit 1
S9L # contact that closes if the pump is working H1P * indication lamp general operation
S3T discharge thermal protector circuit 1 H2P * indication lamp alarm
S6S, S10S *
S11S, S12S
configurable switch for remote function
(rem. start-stop, dual setpoint, enable / disable cap. lim. 1 / 2 / 3 / 4)
H3P * indication lamp operation compressor 1
H5P * changeable output
R1 auxiliary resistance for feedback F6B fuse for primary of TR1
R1F feedback resistance for circuit 1 F7B fuse for secondary of TR1
R4T sensor for evaporator outlet water temperature circuit 1 F9B fuse for secondary of TR2
R5T sensor for ambient temperature F12B fuse for fanmotors circuit 1
Q1M thermal protector compressor motor circuit 1 F8U surge proof fuse for A1P
Q11F-Q14F thermal protector fan motors circuit 1 F1U, F2U, F3U # main fuses
PE main earth terminal F4U,F5U # fuses for evaporator heater
R1P reverse phase protector circuit 1 C1..C3 capacitor
M1S stepless capacity ctrl for compressor circuit 1 E1HC crankcase heater compressor circuit 1
M11F-M14F fan motors circuit 1 E3H * evaporator heater circuit 1
K7F,K8F,K9F fancontactor for circuit1 B2P high pressure transmitter for circuit 1
M1C compressor motor circuit 1 B1P low pressure transmitter for circuit 1
K7A auxiliary relay for safety High Pressure circuit 1 A2P PCB-EEV Driver circuit1
K1A auxiliary relay for safeties circuit 1 A1P PCB-controller
K2A auxiliary relay compressor thermal protector circuit 1 A1 ** current transfo / A-meter for circuit 1
