Functional Control for a Standalone Unit ESIE05-07
2–40 Part 2 – Functional Description
3
1
2
4
5
Related LEDs P pLAN LED's on pCO² controller (Next to pLAN connection - can be consulted with a small mirror
on the unit)
P LED's on front of EEV driver
Legend:
If the alarm LED, the Valve Opening LED and the Valve Closing LED are continuously blinking then
the "EEV NOT CLOSED"-alarm is present.
Overview of alarms
Label Color Status
On Off
RED Error
No error
ORANGE
Communication between pCO
2
and EEV driver(s)
No communication
GREEN
Communication between pCO
2
and EEV driver(s)
No communication
Label Color Status
On Off Blinking
Power green
Power supply to
EEV driver is
present
No power supply to
EEV
EEV battery prob-
lem active
Valve Opening green No valve opening Valve is opening
(not continuously)
Valve Closing green
No valve closing Valve is closing (not
continuously)
Alarm Red Alarm is present
No alarm is present Alarm present (EEV
NOT CLOSED
Error)
pLAN Green
pLAN operates cor-
rectly
pLAN does not
operate (no commu-
nication)
pLAN does not
operates correctly
(or busy to initialize)
Status during normal operation
Circuit Alarms (Circuit will NOT be able to startup)
CIRCUIT1 SAFETY CIRCUIT2 SAFETY
1A9: EEV DRIVER ERROR 2A9: EEV DRIVER ERROR EEV driver is not found
1A9: EEV NOT CLOSED 2A9: EEV NOT CLOSED EEV Valve did not close during
stop (for example during power
off)
Refer to "8. –Reset procedures for
"EEV NOT CLOSED" alarm
