The Functional Controller for DICN ESIE05-07
2–88 Part 2 – Functional Description
3
1
2
4
5
(Remote) cooling
heating
management
P Cooling mode: thermostat function on evaporator.
P Heating mode: thermostat function on condenser.
P Double thermostat: thermostat function on evaporator and condenser.
Remark: heating is only available for water-cooled units.
Dual setpoint
MS Option = yes
(network unit)
MS Option = no
(standalone unit)
Mode cool heat Equal for all units. Dedicated to this unit only
Changing mode cool heat When you change the mode
cool heat on one unit. Then
the status is transferred to all
units
When you change the mode
cool heat on a unit. Then the
status is NOT transferred to
other units
Mode cool heat status Equal for all units Dedicated to this unit only.
Remotely changing mode cool
heat status
Into the service menu of the
master, you can select a
changeable digital input as
"Remote C/H"
Into the service menu of that
unit, you can select a change-
able Digital Input as "Remote
C/H"
Remark: If a digital input is selected as "Remote C/H" on a
slave unit then this switch will only change the status of this unit
when it is in mode "DISCONN. ON/OFF"
MS Option = yes
(network unit)
MS Option = no
(standalone unit)
Setpoint value (1&2) Equal for all units Dedicated to this unit only.
Changing setpoint value When you change the setpoint
of one unit. Then the value is
transferred to all units
When you change the setpoint
of each unit. Then the value is
NOT transferred to other units
Dual setpoint status Equal for all units Dedicated to this unit only.
Changing remotely
dual setpoint status
Into the service menu of the
master, you can select a
changeable Digital Input as
"Dual setpoint"
Into the service menu of that
unit, you can select a change-
able Digital Input as "Dual set-
point"
Remark:
P If in a slave (=not the master) DI="Dual setpoint" then the DI
of that slave will not change the dual setpoint status
P If the slave is standalone (= if MS Option = No ), no set points
are transferred and dual setpoint from the unit changes the
status of that unit.
