The Digital Controller For Large chillers ESIE 05-07
2–142 Part 2 – Functional Description
3
1
2
4
5
Screen 18c This screen allows you to see if the battery is charged
Only visible if EEV1 or EEV2 is present
Screen 19
For more info about this function refer to the corresponding chapter.
Screen 20 This screen allows you to modify the stepless differential thermostat settings
For more info about this function refer to the corresponding chapter.
Remark: Inlet differentional check:
When a unit is on outlet control, then the inlet water temperature is stored in the memory at the moment
the last compressor is stopped by thermostat (not when stopped by safety, change mode...). The unit
will only restart if the thermostat ON is requested and if the inlet evapovator water temperature > stored
value + inldiff.
Line n° Display Description Possible settings
1 EEV DRIVER C1(2) Screen title
3 BATTERY CHARGED Indicates if battery is charged
4 Status N – Y
Line n° Display Description Possible settings
1 SERVICE MENU Screen title
2 SIMULATION: Indicates if the controller is set
to simulation board or standard
parameters
NO – YES
3.1 AI: Setting (default = 0) 0 – 2
3.2 AO: Setting (default = 0) 0 – 1
3.3 DIS.EEV: Setting (default = 0) 0 – 1
4 STL Setting (default = 0) 0 – 1
Line n° Display Description Default
Lower
Limit
Upper
Limit
1 SERVICE MENU Screen title
3.1
3.2
3.3
A:
B:
C:
Setting A
Setting B
Setting C
0.8 °C
0.5 °C
0.2 °C
0.8 °C
0.5 °C
0.2 °C
6 °C
1 °C
0.4 °C
4.1 InlDiff Selection if inlet differential
check is used
YNY
4.2 Valve of inlet differential 0.5 °C 0.3 °C 2 °C
ESIE05-07.book Page 142 Wednesday, October 11, 2006 10:42 AM
