The Digital Controller For Large chillers ESIE 05-07

2–146 Part 2 – Functional Description

Sub screen 1.1 Push the q key to enter the first sub-screen.

Screen 1.2 Push the

q key again to enter the second sub-screen.

Line n° Display Description

1 UNIT HISTORY:XXX

CIRC 1 HISTORY:XXX

CIRC 2 HISTORY:XXX

NET HISTORY:XXX

U WARN HISTORY:XXX

C1WARN HISTORY:XXX

C2WARN HISTORY:XXX

Indicates if it was a unit, circ1, circ2 or network

safety.

XXX is the number of the alarm.

2 XXX:XXXXXXXXXXXX Indicates the safety code and its description.

3.1 INL.E: XX.X°C Actual measured evaporator inlet temperature at

the moment of shutdown.

3.2 INL.C:

XX.X°C

Actual measured condenser inlet temperature at

the moment of shutdown. (The value is shown on

line 4!)

4 OUT.E: XX.X°C Actual measured evaporator outlet temperature at
