ESIE 05-07 General Outline
Part 1 – System Outline 1–33
3
1
4
5
Components The table below lists the components.
No. Component No. Component
1 Evaporator 1 14 Power supply intake
2 Evaporator 2 15 Emergency stop
3 Condenser 16 Switchbox
4 Compressor 1 17 Digital display controller
5 Compressor 2 18 Transportbeam
6 Discharge stop valve 19 Ambient temperature sensor
7 Liquid stop valve 20 Field wiring intake
8 Suction, stop valve (optional) 21 Filter (supplied as kit)
9 Chilled water in 22 Flush plug (Ø25 mm NPT)
10 Chilled water out 23 Counterpipes for welding
(supplied as kit)
11 Leaving water temperature sensor
12 Entering water temperature sensor 24 Flowswitch
13 Drier
