ESIE 05-07 General Outline
Part 1 – System Outline 1–47
3
1
4
5
Components The table below lists the components:
Note:
Q The inlet counterpipe with flowswitch is temporary mounted on side of evaporator for transport.
Q The outlet counterpipe with temperature sensor is temporary mounted on side of evaporator for
transport.
No. Component No. Component
1 Compressor 16 Evaporator entering water tempera-
ture sensor
2Evaporator
3 Flowswitch 17 Evaporator leaving water temperature
sensor
4 Switchbox
5 Compressor Switchbox 18 Discharge stop valve
6 Frame support 19 Main isolator switch (optional)
7 Ballvalve liquid pipe 20 Digital display controller
8 Charge valve 21 Emergency stop
9 Safety valve 22 Power supply intake
10 High pressure switches 23 Field wiring intake
11 Drier 24 Holes for lifting
12 Chilled water in 25 Transportbeam
13 Chilled water out 26 Filter (supplied as kit)
14 Discharge pipe Ø53.98 x 2.00
(spinning end)
27 Flush plug (Ø19 mm NPT)
28 Counterpipes for welding
(supplied as kit)
15 Liquid pipe Ø34.90 x 1.25
(spinning end)
ESIE05-07.book Page 47 Wednesday, October 11, 2006 10:42 AM
