ESIE 05-07 General Outline
Part 1 – System Outline 1–49
3
1
4
5
Components The table below lists the components:
Note:
Q The inlet counterpipe with flowswitch is temporary mounted on side of evaporator for transport.
Q The outlet counterpipe with temperature sensor is temporary mounted on side of evaporator for
transport.
No. Component No. Component
1 Compressor 16 Evaporator entering water tempera-
ture sensor
2 Evaporator 17 Evaporator leaving water temperature
sensor
3 Flowswitch
4 Switchbox 18 Discharge stop valve
5 Compressor Switchbox 19 Main isolator switch (optional)
6 Frame support 20 Digital display controller
7 Ballvalve liquid pipe 21 Emergency stop
8 Charge valve 22 Power supply intake
9 Safety valve 23 Field wiring intake
10 High pressure switches 24 Holes for lifting
11 Drier 25 Transportbeam
12 Chilled water in 26 Filter (supplied as kit)
13 Chilled water out 27 Flush plug (Ø19 mm NPT)
14 Discharge pipe Ø53.98 x 2.00
(spinning end)
28 Counterpipes for welding
(supplied as kit)
15 Liquid pipe Ø34.90 x 1.25
(spinning end)
29 Mixed outled water temperature sen-
sor (rolled up in switchbox)
ESIE05-07.book Page 49 Wednesday, October 11, 2006 10:42 AM
