ESIE 05-07 General Outline
Part 1 – System Outline 1–57
3
1
4
5
Components The table below lists the components:
No. Component No. Component
1 Evaporator 1 16 Switchbox
2 Evaporator 2 17 Digital display controller
3 Condenser 18 Transportbeam
4 Compressor 1 19 Ambient temperature sensor
5 Compressor 2 20 Field wiring intake
6 Discharge stop valve 21 Economizer 1
7 Liquid stop valve 22 Economizer 2
8 Suction stop valve (optional) 23 Heatrecovery condenser 1
9 Chilled water in 24 Heatrecovery condenser 2
10 Chilled water out 25 Inverterbox
11 Leaving water temperature sensor 26 Filter (supplied as kit)
12 Entering water temperature sensor 27 Flush plug (Ø13 mm NPT)
13 Drier + charge valve 28 Counterpipes for welding
(supplied as kit)
14 Power supply intake
15 Emergency stop 29 Flowswitch
ESIE05-07.book Page 57 Wednesday, October 11, 2006 10:42 AM
