ESIE 05-07 Piping Layout
Part 1 – System Outline 1–67
3
1
4
5
Symbols The table below describes the symbols.
Symbol Description Symbol Description
M11, -16F Condenser fan motor B2, 5P High pressure transmitter
M21, -26F Condenser fan motor Y11 Unloader solenoid valve
M1C, M2C Compressor motor Y21 Unloader solenoid valve
S1, 2HP High pressure switch Y15, 25S Liquid injection solenoid valve
S14, 15HP High pressure switch Y15, 26S Liquid line solenoid valve
S3, 4T Dicharge temperature
controller
Check valve
R3T Inlet water evap. temp sensor Flare connection
R4T Outlet water evap. temp
sensor
Screw connection
R6T Outlet water evap. temp
sensor
Flange connection
R7T Mixed outlet water temp
sensor
Pinched pipe
R5T Ambient temperature sensor Spinned pipe
B1, 4P Low pressure transmitter
ESIE05-07.book Page 67 Wednesday, October 11, 2006 10:42 AM
