ESIE 05-07 Piping Layout
Part 1 – System Outline 1–71
3
1
4
5
Symbols The table below describes the symbols.
Symbol Description Symbol Description
M11F Condenser fan motor B1P Low pressure transmitter
M12F Condenser fan motor B2P High pressure transmitter
M13F Condenser fan motor Y11S Unloader solenoid valve
M14F Condenser fan motor Y14S Liquid injection solenoid valve
M1C Compressor motor1 Y15S Liquid line solenoid valve
S1HP High pressure switch Check valve
S14HP High pressure switch Flare connection
S3T Discharge temperature controller Screw connection
R3T Inlet water evap. temp. sensor Flange connection
R4T Outlet water evap. temp. sensor Pinched pipe
R5T Ambient temperature sensor Spinned pipe
